Continuous type nuts roasting machine, is also called continuous type nut roaster, it is mainly composed of conveyor system and roasting furnace. The conveyor system consists of conveyor belts made of steel chain plates, which carry nut materials pass through the roasting furnace, to make the production more efficiently.
Features of Continuous Cashew Nuts Roasting Equipment
The heating type can be electric heating, steam heating or hot air heating.
It has independent PID temperature controlling for each section, the furnace temperature is uniform. Conveyor speed can be adjusted freely, the operation is smooth, production is continous and high efficient.
Working principle of Automatic Cashew Nut Roaster Machine
Continuous roasting machine is a type of stream jetting roaster, hot air sprayed through the holes roast the materials on conveyor belt up and down at the same time, for the jet gas velocity is up to more than 15 m/s, so the membrane of transfer convection is very thin, the coefficient of heat transfer is big, and heating speed is fast. For materials of airtight class content, the jet stream from above still returns to the above, that from the under holes also return back there to participate in the heat transmission circulation to make the roasting effect better.
Advantages of Continuous Nuts Roasting Machine
1.The chain plate conveyor moving back and forth inside the roasting chamber, make the heating more even and thorough.
2.When roasting, the water vapor flow out from the wet vent hole, so as to achieve the purpose of drying or roasting.
3.Roasting time is 20 to 30 minutes commonly, and the time can be adjusted according to different materials.
4.The chain conveyor is made of heat resistant steel material, and the roasting chamber is also made of high temperature resistant material.
Scope of application:
This continuous type roaster is mainly used for the drying or roasting of the materials in sheets, strips or particles, also suitable for dehydrated vegetables and Chinese herbal medicine pieces which are of high moisture content and do not allow the high temperature.
